NFPA Pneumatic cylinders
Product Features:
- Hydraulic and pneumatic configurations available
- Various rod and bore combinations
- Steel, stainless steel and aluminum assemblies
- Built to NFPA standards or custom designed by our engineering team
- Various mounting styles available
- Tempsonic positioners available
- Custom units to replace any manufacturer
| BORE | STROKE | ROD | PORT | PART NUMBER |
| 1.5 | 6 | 0.625 | 3/8 NPT | TRP1.50MP1LU14X6.00 |
| 1.5 | 12 | 0.625 | 3/8 NPT | TRP1.50MP1LU14X12.00 |
| 1.5 | 18 | 0.625 | 3/8 NPT | TRP1.50MP1LU14X18.00 |
| 1.5 | 24 | 0.625 | 3/8 NPT | TRP1.50MP1LU14X24.00 |
| 2 | 6 | 0.625 | 3/8 NPT | TRP2.00MP1LU14X6.00 |
| 2 | 12 | 0.625 | 3/8 NPT | TRP2.00MP1LU14X12.00 |
| 2 | 18 | 0.625 | 3/8 NPT | TRP2.00MP1LU14X18.00 |
| 2 | 24 | 0.625 | 3/8 NPT | TRP2.00MP1LU14X24.00 |
| 2.5 | 6 | 0.625 | 3/8 NPT | TRP2.50MP1LU14X6.00 |
| 2.5 | 12 | 0.625 | 3/8 NPT | TRP2.50MP1LU14X12.00 |
| 2.5 | 18 | 0.625 | 3/8 NPT | TRP2.50MP1LU14X18.00 |
| 2.5 | 24 | 0.625 | 3/8 NPT | TRP2.50MP1LU14X24.00 |
| 3.25 | 6 | 1 | 1/2 NPT | TRP3.25MP1LU14X6.00 |
| 3.25 | 12 | 1 | 1/2 NPT | TRP3.25MP1LU14X12.00 |
| 3.25 | 28 | 1 | 1/2 NPT | TRP3.25MP1LU14X18.00 |
| 3.25 | 24 | 1 | 1/2 NPT | TRP3.25MP1LU14X24.00 |
| 4 | 6 | 1 | 1/2 NPT | TRP4.00MP1LU14X6.00 |
| 4 | 12 | 1 | 1/2 NPT | TRP4.00MP1LU14X12.00 |
| 4 | 18 | 1 | 1/2 NPT | TRP4.00MP1LU14X18.00 |
| 4 | 24 | 1 | 1/2 NPT | TRP4.00MP1LU14X24.00 |
| 5 | 6 | 1 | 1/2 NPT | TRP5.00MP1LU14X6.00 |
| 5 | 12 | 1 | 1/2 NPT | TRP5.00MP1LU14X12.00 |
| 5 | 18 | 1 | 1/2 NPT | TRP5.00MP1LU14X18.00 |
| 5 | 24 | 1 | 1/2 NPT | TRP5.00MP1LU14X24.00 |
| 6 | 6 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X6.00 |
| 6 | 12 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X12.00 |
| 6 | 18 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X18.00 |
| 6 | 24 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X24.00 |
| 8 | 6 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X6.00 |
| 8 | 12 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X12.00 |
| 8 | 18 | 1.375 | 3/4 NPT | TRP6.00MP1LU14X18.00 |
Prices are list prices only, please contact Titan for quantity discounts.Sizes are in inches. Metric sizes available upon request.
Cylinders can be customized to meet any specifications including but not limited to: cushions, proximity sensors, port sizes and orientation. Please contact Titan for details.
Lead time is 3-4 weeks unless otherwise specified at confirmation of order.
| BORE | STROKE | ROD | PIN DIA | PORT | PART NUMBER |
| 1.5 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP3LU14X6.00 |
| 1.5 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP3LU14X12.00 |
| 1.5 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP3LU14X18.00 |
| 1.5 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP3LU14X24.00 |
| 2 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP3LU14X6.00 |
| 2 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP3LU14X12.00 |
| 2 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP3LU14X18.00 |
| 2 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP3LU14X24.00 |
| 2.5 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP3LU14X6.00 |
| 2.5 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP3LU14X12.00 |
| 2.5 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP3LU14X18.00 |
| 2.5 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP3LU14X24.00 |
| 3.25 | 6 | 1 | 0.75 | 1/2 NPT | TRP3.25MP3LU14X6.00 |
| 3.25 | 12 | 1 | 0.75 | 1/2 NPT | TRP3.25MP3LU14X12.00 |
| 3.25 | 28 | 1 | 0.75 | 1/2 NPT | TRP3.25MP3LU14X18.00 |
| 3.25 | 24 | 1 | 0.75 | 1/2 NPT | TRP3.25MP3LU14X24.00 |
| 4 | 6 | 1 | 0.75 | 1/2 NPT | TRP4.00MP3LU14X6.00 |
| 4 | 12 | 1 | 0.75 | 1/2 NPT | TRP4.00MP3LU14X12.00 |
| 4 | 18 | 1 | 0.75 | 1/2 NPT | TRP4.00MP3LU14X18.00 |
| 4 | 24 | 1 | 0.75 | 1/2 NPT | TRP4.00MP3LU14X24.00 |
| 5 | 6 | 1 | 0.75 | 1/2 NPT | TRP5.00MP3LU14X6.00 |
| 5 | 12 | 1 | 0.75 | 1/2 NPT | TRP5.00MP3LU14X12.00 |
| 5 | 18 | 1 | 0.75 | 1/2 NPT | TRP5.00MP3LU14X18.00 |
| 5 | 24 | 1 | 0.75 | 1/2 NPT | TRP5.00MP3LU14X24.00 |
| 6 | 6 | 1.375 | 1 | 3/4 NPT | TRP6.00MP3LU14X6.00 |
| 6 | 12 | 1.375 | 1 | 3/4 NPT | TRP6.00MP3LU14X12.00 |
| 6 | 18 | 1.375 | 1 | 3/4 NPT | TRP6.00MP3LU14X18.00 |
| 6 | 24 | 1.375 | 1 | 3/4 NPT | TRP6.00MP3LU14X24.00 |
| 8 | 6 | 1.375 | 1 | 3/4 NPT | TRP8.00MP3LU14X6.00 |
| 8 | 12 | 1.375 | 1 | 3/4 NPT | TRP8.00MP3LU14X12.00 |
| 8 | 18 | 1.375 | 1 | 3/4 NPT | TRP8.00MP3LU14X18.00 |
| 8 | 24 | 1.375 | 1 | 3/4 NPT | TRP8.00MP3LU14X24.00 |
Sizes are in inches. Metric sizes available upon request.
Prices are list prices only, please contact Titan for quantity discounts.
Cylinders can be customized to meet any specifications including but not limited to: cushions, proximity sensors, port sizes and orientation. Please contact Titan for details.
Lead time is 3-4 weeks unless otherwise specified at confirmation of order.
| BORE | STROKE | ROD | PIN DIA | PORT | PART NUMBER |
| 1.5 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP5LU14X6.00 |
| 1.5 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP5LU14X12.00 |
| 1.5 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP5LU14X18.00 |
| 1.5 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP1.50MP5LU14X24.00 |
| 2 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP5LU14X6.00 |
| 2 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP5LU14X12.00 |
| 2 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP5LU14X18.00 |
| 2 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP2.00MP5LU14X24.00 |
| 2.5 | 6 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP5LU14X6.00 |
| 2.5 | 12 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP5LU14X12.00 |
| 2.5 | 18 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP5LU14X18.00 |
| 2.5 | 24 | 0.625 | 0.5 | 3/8 NPT | TRP2.50MP5LU14X24.00 |
| 3.25 | 6 | 1 | 0.75 | 1/2 NPT | TRP3.25MP5LU14X6.00 |
| 3.25 | 12 | 1 | 0.75 | 1/2 NPT | TRP3.25MP5LU14X12.00 |
| 3.25 | 28 | 1 | 0.75 | 1/2 NPT | TRP3.25MP5LU14X18.00 |
| 3.25 | 24 | 1 | 0.75 | 1/2 NPT | TRP3.25MP5LU14X24.00 |
| 4 | 6 | 1 | 0.75 | 1/2 NPT | TRP4.00MP5LU14X6.00 |
| 4 | 12 | 1 | 0.75 | 1/2 NPT | TRP4.00MP5LU14X12.00 |
| 4 | 18 | 1 | 0.75 | 1/2 NPT | TRP4.00MP5LU14X18.00 |
| 4 | 24 | 1 | 0.75 | 1/2 NPT | TRP4.00MP5LU14X24.00 |
| 5 | 6 | 1 | 0.75 | 1/2 NPT | TRP5.00MP5LU14X6.00 |
| 5 | 12 | 1 | 0.75 | 1/2 NPT | TRP5.00MP5LU14X12.00 |
| 5 | 18 | 1 | 0.75 | 1/2 NPT | TRP5.00MP5LU14X18.00 |
| 5 | 24 | 1 | 0.75 | 1/2 NPT | TRP5.00MP5LU14X24.00 |
| 6 | 6 | 1.375 | 1 | 3/4 NPT | TRP6.00MP5LU14X6.00 |
| 6 | 12 | 1.375 | 1 | 3/4 NPT | TRP6.00MP5LU14X12.00 |
| 6 | 18 | 1.375 | 1 | 3/4 NPT | TRP6.00MP5LU14X18.00 |
| 6 | 24 | 1.375 | 1 | 3/4 NPT | TRP6.00MP5LU14X24.00 |
| 8 | 6 | 1.375 | 1 | 3/4 NPT | TRP8.00MP5LU14X6.00 |
| 8 | 12 | 1.375 | 1 | 3/4 NPT | TRP8.00MP5LU14X12.00 |
| 8 | 18 | 1.375 | 1 | 3/4 NPT | TRP8.00MP5LU14X18.00 |
| 8 | 24 | 1.375 | 1 | 3/4 NPT | TRP8.00MP5LU14X24.00 |
Sizes are in inches. Metric sizes available upon request.
Prices are list prices only, please contact Titan for quantity discounts.
Cylinders can be customized to meet any specifications including but not limited to: cushions, proximity sensors, port sizes and orientation. Please contact Titan for details.
Lead time is 3-4 weeks unless otherwise specified at confirmation of order.
| BORE | STROKE | ROD | PORT | PART NUMBER |
| 1.5 | 6 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X6.00 |
| 1.5 | 12 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X12.00 |
| 1.5 | 18 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X18.00 |
| 1.5 | 24 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X24.00 |
| 2 | 6 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X6.00 |
| 2 | 12 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X12.00 |
| 2 | 18 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X18.00 |
| 2 | 24 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X24.00 |
| 2.5 | 6 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X6.00 |
| 2.5 | 12 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X12.00 |
| 2.5 | 18 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X18.00 |
| 2.5 | 24 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X24.00 |
| 3.25 | 6 | 1 | 1/2 NPT | TRP3.25MF1LU14X6.00 |
| 3.25 | 12 | 1 | 1/2 NPT | TRP3.25MF1LU14X12.00 |
| 3.25 | 28 | 1 | 1/2 NPT | TRP3.25MF1LU14X18.00 |
| 3.25 | 24 | 1 | 1/2 NPT | TRP3.25MF1LU14X24.00 |
| 4 | 6 | 1 | 1/2 NPT | TRP4.00MF1LU14X6.00 |
| 4 | 12 | 1 | 1/2 NPT | TRP4.00MF1LU14X12.00 |
| 4 | 18 | 1 | 1/2 NPT | TRP4.00MF1LU14X18.00 |
| 4 | 24 | 1 | 1/2 NPT | TRP4.00MF1LU14X24.00 |
| 5 | 6 | 1 | 1/2 NPT | TRP5.00MF1LU14X6.00 |
| 5 | 12 | 1 | 1/2 NPT | TRP5.00MF1LU14X12.00 |
| 5 | 18 | 1 | 1/2 NPT | TRP5.00MF1LU14X18.00 |
| 5 | 24 | 1 | 1/2 NPT | TRP5.00MF1LU14X24.00 |
| 6 | 6 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X6.00 |
| 6 | 12 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X12.00 |
| 6 | 18 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X18.00 |
| 6 | 24 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X24.00 |
Sizes are in inches. Metric sizes available upon request.
Prices are list prices only, please contact Titan for quantity discounts.
Cylinders can be customized to meet any specifications including but not limited to: cushions, proximity sensors, port sizes and orientation. Please contact Titan for details.
Lead time is 3-4 weeks unless otherwise specified at confirmation of order.
| BORE | STROKE | ROD | PORT | PART NUMBER |
| 1.5 | 6 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X6.00 |
| 1.5 | 12 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X12.00 |
| 1.5 | 18 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X18.00 |
| 1.5 | 24 | 0.625 | 3/8 NPT | TRP1.50MF1LU14X24.00 |
| 2 | 6 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X6.00 |
| 2 | 12 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X12.00 |
| 2 | 18 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X18.00 |
| 2 | 24 | 0.625 | 3/8 NPT | TRP2.00MF1LU14X24.00 |
| 2.5 | 6 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X6.00 |
| 2.5 | 12 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X12.00 |
| 2.5 | 18 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X18.00 |
| 2.5 | 24 | 0.625 | 3/8 NPT | TRP2.50MF1LU14X24.00 |
| 3.25 | 6 | 1 | 1/2 NPT | TRP3.25MF1LU14X6.00 |
| 3.25 | 12 | 1 | 1/2 NPT | TRP3.25MF1LU14X12.00 |
| 3.25 | 28 | 1 | 1/2 NPT | TRP3.25MF1LU14X18.00 |
| 3.25 | 24 | 1 | 1/2 NPT | TRP3.25MF1LU14X24.00 |
| 4 | 6 | 1 | 1/2 NPT | TRP4.00MF1LU14X6.00 |
| 4 | 12 | 1 | 1/2 NPT | TRP4.00MF1LU14X12.00 |
| 4 | 18 | 1 | 1/2 NPT | TRP4.00MF1LU14X18.00 |
| 4 | 24 | 1 | 1/2 NPT | TRP4.00MF1LU14X24.00 |
| 5 | 6 | 1 | 1/2 NPT | TRP5.00MF1LU14X6.00 |
| 5 | 12 | 1 | 1/2 NPT | TRP5.00MF1LU14X12.00 |
| 5 | 18 | 1 | 1/2 NPT | TRP5.00MF1LU14X18.00 |
| 5 | 24 | 1 | 1/2 NPT | TRP5.00MF1LU14X24.00 |
| 6 | 6 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X6.00 |
| 6 | 12 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X12.00 |
| 6 | 18 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X18.00 |
| 6 | 24 | 1.375 | 3/4 NPT | TRP6.00MF1LU14X24.00 |
Sizes are in inches. Metric sizes available upon request.
Prices are list prices only, please contact Titan for quantity discounts.
Cylinders can be customized to meet any specifications including but not limited to: cushions, proximity sensors, port sizes and orientation. Please contact Titan for details.
Lead time is 3-4 weeks unless otherwise specified at confirmation of order.
